GNEE tuaj yeem muab tauS235 JRsteel phaj, uas muaj cov yas zoo, toughness, thiab weldability, nrog lub zog qis zog ntawm 185 txog 235 MPa.
TS EN 10025S235JR (steel 1.0038)yog non-alloy, low carbon, manganese-muaj structuralhlaufeem ntau muab nyob rau hauv ib qho kev kho tsis zoo los yog normalized.
TS EN 10025S235JR hlauyog kub-kuav los tiag ntshiab structuralhlau.
Weldability: Qib steel no feem ntau haum rau vuam
S235JR 1.0038 Cov Qauv Hlau Phaj Loj:
- Thickness ntawm 6 mus rau 130 mm.
- Dav hauv Tshuag: 2000 - 2500 - 3000 hli.
- Ntev hauv Tshuag: 3000 - 4000 - 6000 - 8000 - 12000 mm.
Tshuaj muaj pes tsawg leeg ntawm steel S235JR (1.0038 Steel)
| C | max 0.2 |
| Mn | max 1.4 tsi |
| P | max 0.04 |
| S | max 0.04 |
| N | max 0.012 |
| Cu | max 0.55 |
| CEV | max 0.38 |
Mechanical Properties steel hlau S235JR (1.0038 steel)
| Yield zog | 185-235 MPa |
| Tensile zog | 340-510 MPa |
| Elongation thaum so | 21-26% |
| Hardness | 120 |
| Module ntawm elasticity | 210 GPa |
Cov qib sib npaug ntawm cov hlau S235JR (1.0038)
| EN | ASTM | DIN, NWS | JIS | AFNOR | BS | HG | GB | GOST |
| S235 JR | 1015 | RSt 37-2 | Qauv: SM400A | E24-2 | 40A | 230G | Q235A | St 2 ps |
| A283C | St 37-2 | SIB 400 | 40B | Q235B | St 2 sp | |||
| QibC | Q235D | St3ps ib | ||||||
| QibD | St3sp | |||||||
| TSI 33 |
Cim npe nrov: S235JR 1.0038 Carbon Steel Phaj, Tuam Tshoj S235JR 1.0038 Carbon Steel Phaj manufacturers, lwm tus neeg, Hoobkas
